Product Descriptions：
| Characteristics: | Photosensitive Blue Glass |
| Type: | Shortpass Filter |
| Central Wavelength (CWL): | 600nm ± 5nm |
| Peak Transmittance: | >90% |
| Optical Density (OD): | OD2-3 |
| Shape: | Round, Square, Custom Shape |
| Color: | Blue |
| Surface Quality: | 40/20, or 60/40 scratch-dig |
| Dimension: | Specified** |
| Thickness: | Specified** |
| Substrate: | Ultra-clear glass,K9,BK7,B270,D2637T, Quartz Glass(Fused Silica) or other specified. |
| Remark： (1)Spectral range:380-1100nm (2) Size customized: 86x86mm, 80x80mm, other can customized, max. 300x300mm (3) Thickness available: 0.21、0.3、0.55、0.7、1.0、1.1、1.5、1.8、2.0、3.0mm…etc. | |
Measured Spectral measurement
 |
Picture 1: Blue Glass 650nm+AR Spectral measurement |
What is photosensitive blue glass?
Photosensitive blue glass refers to a special type of light-sensitive glass that appears blue or develops a blue color upon exposure to light. It is a subset of photosensitive glass and photochromic glass, tailored to exhibit blue hues.
What is typical application for photosensitive blue glass?
Shenzhen Hengda Liyuan Optoelectronics introduced advanced optical technology that apply depositing nanomaterials through ion-assisted evaporation onto a multilayer hard film in a high vacuum environment which coating layer is firm and has good tightness, and small bandwidth drift. Liyuan optoelectronics have been focus on optical coating for more than 17 years and offer one-stop optical filters solution including Narrow Bandpass Filters, IR cut-off Filters, Longpass & Short Filters, Notch Filters, ND filters, Star filters and Optical sapphire block.
other IR cut-off filters in stock from Liyuan Optoelectronics: IR600 IR630 IR650 IR680 IR700 IR730 IR750…etc.
