Product Descriptions:
| Characteristics: | 740nm Bandpass Filter |
| Type: | Interference type |
| Central Wavelength (CWL): | 740+-5nm |
| Full Width at Half Maximum(FWHM): | 45/535nm |
| Peak Transmittance(%) : | >92% |
| Surface Quality: | 60/40 scratch-dig |
| Optical Density (OD): | OD2-OD3 |
| Color: | Black |
| Shape： | Square, Round, Irregular Shape |
| Dimension(mm): | specified** |
| Thickness(mm): | specified** |
| Substrate: | Ultra-clear glass,K9,BK7,B270,D2637T, Quartz Glass(Fused Silica) or other specified |
| Remark：
Spectral range:350-1100nm
*Customized capability: 380-2500nm, stock for 10nm intervals.
**Common for 86x86mm, 80x80mm, other can customized, max. 300x300mm
*** Thickness available: 0.21、0.3、0.55、0.7、1.0、1.1、1.5、1.8、2.0、3.0mm…etc. |
Measured Spectral Graph – 740nm Bandpass filter:
 |
| Picture 1: BP740-45nm Spectral Graph measurement |
|
| Picture 2: BP740-535nm Spectral Graph measurement |
What is typical application for 740nm bandpass filters?
A 740nm bandpass filter is a precision optical component that transmits only light within a narrow wavelength band centered at 740nm, while blocking all ultraviolet, visible and other off-band near-infrared light. Typical application for 740nm bandpass filters are very broad, include biological fluorescence imaging, medical optical detection and spectral analysis. It also applies to plant growth monitoring, industrial photoelectric sensing and laser signal extraction, filtering interference light to improve signal purity and testing accuracy.
4.What are key parameters when choose for a suitable Bandpass Filter?
When selecting a Narrow Bandpass Filter, normally the following factors need to be taken into consideration：
- Central Wavelength (CWL)：CWL is one of key parameter to designate first, it refer to the central wavelength at stable high transmission rate passband.
- Peak or Average Transmittance: typically ≥90%, Higher transmittance might need Anti-reflective(AR) coating.
- Full width at half maximum (FWHM): FWHM refer to the interval between the two wavelength points where the transmittance rate reaches 50%.
- Blocking rate: usually in terms of optical density(OD), OD2-OD3 for standard and higher will be OD4-OD6 per requirement.
- Angle of Incidence (AOI): AOI need to be considered as Interference Filter is angle sensitive, 0° AOI by default, other AOI e.g. 30/45° need to be specified.
- Physical and environmental requirement: Substrate type, dimensions and thickness, surface quality, and environmental durability.
